LED Rotating Warning Light LTE-1101
Compact LTE-1101 rotating warning light with a built-in buzzer, IP55 protection and bolt-fixed installation. Available in multiple voltage, light-source and lens-color configurations, with an LTD magnetic-base option also listed.
Specifications
Product Overview
The LTE-1101 rotating warning light combines a visual signal with a built-in buzzer for machinery, equipment and site warning applications. The legacy specification lists LED beads or incandescent bulbs, DC12V, DC24V, AC220V and AC380V options, and red, yellow, blue or green lenses. The LTE configuration uses a three-point bolt-fixed base; the parameter image also lists an LTD magnetic type, but its complete model number requires confirmation. The body measures 163 × 102mm and the listed protection rating is IP55. The legacy table states a sound level greater than 90dB, while one promotional image states 110dB, so the exact rated value and measurement distance remain subject to confirmation.
Key Features
- Built-in buzzer with sound level listed above 90dB on the legacy specification table
- Red, yellow, blue and green lens options
- DC12V, DC24V, AC220V and AC380V voltage options
- LTE bolt-fixed installation and optional LTD magnetic-base configuration
- IP55 rain and dust protection listed in the legacy material
- Compact 163 × 102mm body with three-point bolt mounting
Frequently Asked Questions
What is the difference between LTE and LTD mounting types?+
The legacy parameter image describes LTE as the bolt-fixed type and LTD as the magnetic type. The complete LTD model number should be confirmed before ordering.
Which voltage options are listed?+
The listed options are DC12V, DC24V, AC220V and AC380V. Confirm the required voltage in the inquiry.
Which lens colors are available?+
The legacy material lists red, yellow, blue and green lens options.
What is the protection rating?+
The listed protection rating is IP55. Final installation should still consider cable entry and mounting conditions.
What is the buzzer sound level?+
The legacy specification table states greater than 90dB, while one promotional image states 110dB. The exact rated value and measurement distance require confirmation.
Applications
Suitable for cranes, industrial machinery, road construction areas, parking signals, stations, docks, automatic gates and equipment fault indication. Select voltage, lens color, light source and mounting type for the intended installation.
